<p> <span style="font-size:20px;"><strong>Love on every trip</strong></span> <br> The one-piece front face with wide light panel shows atmosphere and fashion in stability. <br>8.6-inch super large screen, information display is more comprehensive and clearer. </p>

C23 electric leisure tricycle丨Full voltage endurance matrix, comfortable control defines a new paradigm of travel

Power system: precise power matching, full-scenario energy efficiency optimization

Motor core: 48/60V-500W30H rare earth permanent magnet motor

Using 30H high magnetic steel material, no-load speed 520 rpm, energy efficiency ratio of 8.5W·h/km, compared with the traditional motor energy consumption is reduced by 12%. 500W power output can cope with 15° slope, especially suitable for flat road conditions in the city and light-load travel, sine wave drive technology keeps the running noise below 58dB, and the riding is quiet and unstuck.

Controller advantage: 12-tube 500W intelligent control

Equipped with a 12-tube sine wave controller, supports 48V-60V wide voltage input, current output accuracy ±0.3A, with overcurrent protection (30A automatic cut-off), undervoltage protection (42V warning) and temperature control functions, to ensure the stable operation of the motor under different battery specifications, and extend the service life by 20%.

Battery configuration: six specifications of battery life solutions, covering all scenarios

•48V20AH economic model:

Battery life is 35-45 kilometers, suitable for high-frequency short-distance travel within 3 kilometers (such as buying groceries and picking up children), the battery weighs only 12kg, the body is light and easy to push, and the 220V power supply is fully charged in 4-5 hours, which is suitable for daily travel for elderly users.

•48V32AH long-range model:

The capacity is increased by 60%, the battery life is 50-60 kilometers, and it supports single-day cross-region commuting. The BMS battery management system monitors the battery cell status in real time, and the cycle life exceeds 800 times, which is suitable for office workers to commute 5-10 kilometers.

•60V20AH standard model:

The voltage is increased by 25%, the power response speed is accelerated by 10%, the battery life is 45-55 kilometers, and the power and battery life are balanced. It is suitable for single-person loading (rear cargo box load 50kg) or short-distance riding for two people.

•60V32AH enhanced version:

60V high-voltage system with 32AH large capacity, 60-70km range, supports 2 adults and 1 child outing, more stable motor power output when climbing, suitable for mixed urban and suburban road conditions.

•72V20AH power version:

72V high-energy system, 30% power increase, can cope with 20° slope, 50-60km range, supports fast charging (3 hours to 80%), suitable for frequent climbing scenes in urban and rural areas.

•72V32AH flagship version:

Full specification top configuration, 70-80km range, 72V+500W motor combination realizes the dual advantages of "long distance + strong power", suitable for long-distance freight (vehicle load 180kg) or cross-regional long-distance travel.

Body design: 2010mm golden ratio, both comfortable and passable

•Body specifications: 20108801123MM, wheelbase 1350MM, standard double seat cushion (width 800MM), leg space up to 600MM, no pressure for adults; ground clearance 140MM, smooth passage of speed bumps and small steps, better passability than similar models.

•Front-end Ф31 hydraulic suspension:

Built-in dual damping springs, road vibration filtering efficiency of 60%, compared with traditional spring shock absorption, vertical bump amplitude is reduced by 40%, with ergonomic seats, long-term riding waist fatigue is reduced by 35%, especially suitable for elderly users and family travel.

Safety configuration: hand-foot linkage braking + explosion-proof tire technology

• Braking system: innovative hand-foot linkage structure, left handle/right pedal dual control channels, braking response time ≤ 0.3 seconds, braking distance ≤ 2.2 meters at 20km/h, equipped with automatic gap compensation function to avoid braking force attenuation after long-term use, taking into account the operating habits of different users.

• Tire advantages: 3.00-10 tubeless steel wire tire, Kevlar puncture-proof layer added to the tread, puncture resistance increased by 60%, tire pressure maintenance time extended to 5 months, with aluminum alloy wheels, lightweight design reduces energy consumption by 8%, no need for frequent air replenishment, more worry-free.

Differentiation of model selling points

48V20AH elderly safety model

• Core keywords: low-speed safety, light and easy to control, voice prompts

• Scenario adaptation: users over 65 years old travel in the community, the maximum speed limit is 18km/h, the body weighs only 88kg, easy to push, standard reflective strips and steering voice reminders, safer travel at night.

60V32AH Family Outing Model

•Core Keywords: Three-person ride, long battery life, hydraulic shock absorption

•Scenario adaptation: Family weekend suburban riding (can carry 2 adults and 1 child), rear storage box with a volume of 50L, standard USB charging port and awning interface, hydraulic suspension to filter bumps, suitable for traveling with the elderly and children.

72V32AH flagship freight model

•Core Keywords: strong load, long-distance battery life, fast charging technology

•Scenario adaptation: short-distance freight for small merchants (cargo 100kg), urban and rural cross-regional transportation, 72V system climbing torque increased by 35%, 32AH battery supports 100 kilometers round trip per day, adapted to commercial high-frequency use needs.

C23 builds an industry-leading battery life matrix with "six specifications of batteries + full voltage adaptation". From safe transportation for the elderly to commercial load transportation, each configuration accurately matches user needs. The hand-foot linkage brake and Ф31 hydraulic suspension take into account both safety and comfort, and are an all-round solution for urban micro-mobility, family life and commercial transportation.
